I love this tent, I am 6'4" and really needed a tent with a longer bathtub. Fits me my dog, and my pack and still has space.
Designed for taller hikers, the DupleXL takes all of the great features from the Duplex and scales them up. The DupleXL boasts an 8 foot long (2.44m) usable floor length, perfect for hikers up to 7'0".
From the Wonderland Trail to the Wind River Range, redefine your boundaries as you cover more trail with an ultralight tent designed to specifically handle the demands of taller long distance backpackers.
The DupleXL is lightweight, roomy, well-ventilated, packs down small, pitches easily, and can be set up in the tightest of spaces, making this tent the sweet spot when it comes to size, weight, and features.
An optional flat groundsheet is available for added protection here.
*THE DUPLEXL DOES NOT SUPPORT OUR DUPLEX FLEX KIT
- Sets up with two trekking poles adjusted to around 48" (122 cm). Slightly taller or shorter fixed length poles will also work. If you do not use trekking poles, we have 48" tent poles available here. Eight stakes are required for this tent.
- Symmetrical design allows two tall adults to lay side by side in either direction. Two people can also sit upright side by side facing out either door while removing shoes or while reaching out to cook or access gear just outside the tent.
- Any of the four storm doors can be opened or closed independently. Leave all four open on nice weather nights for a breeze and great views. Close the upwind doors to block cold wind, or close all four for 360° rain protection. The overlapping doors are closed with custom made metal hooks, with a toggle at the center to keep them pinned.
- Overlapping storm doors allow for a small amount of airflow without the need for additional venting. There are no zippers on the doors that could potentially fail over time.
- Each screen door has a rainbow zipper which allows easy entry regardless of which storm doors are closed, and they give you access to every vestibule area. Each screen door conveniently drops inwards rather than hanging in your way. No need to roll it up or secure it.
- The tarp overhangs the bathtub floor by 4-5 inches (12 cm). In calm rain or under wet trees one or two doors can be left open for air flow without water dripping on the floor space. In almost all conditions at least one downwind door can be left open for air.
- This tent has a solid, sewn in 8 inch (20 cm) tall bathtub floor. The bathtub floor is a rectangle 44 inches wide by 8 feet long (114cm x 2.44m). Plenty of space for two taller people to stretch out or a ton of room for one taller hiker plus gear.
- Mesh pockets are conveniently located near each screen door so that they can be accessed from inside or outside the tent. They are a good place to store your cell phone, glasses, headlamp, the tent stuff sack, and spare seam tape (included). The pockets are about 8" x 8" (20 cm x 20 cm).
- A separate groundsheet is NOT required for this shelter. The floor material is reasonably durable, and all Dyneema® Composite Fabric gear can be easily patched in the field with repair tape. If you do prefer to use a groundsheet as a precaution, Flat Groundsheets are available.
- There is screen between the bathtub floor and the walls at the ends of the tarp. An elastic cord keeps the bathtub elevated ensuring the screen slopes downwards away from the bathtub. Any condensation, which single wall shelters may experience, will run down the walls and out through the downward sloping screen, rather than onto the floor. Click here for tips to avoid condensation.
- All of our tents do pretty well in the wind. The material can handle high wind loads. As long as your stakes stay in the ground (use rocks if available) your tent will stay standing. Dyneema® Composite Fabric is not a particularly noisy fabric; however, almost any tent will make a little noise in the wind. Earplugs are not a bad idea for windy nights.
- Dyneema Composite Fabric is naturally waterproof and is not treated with any potentially harmful chemicals such as flame retardants or water repellents.
- All Zpacks gear has a two year limited warranty against defects in materials or workmanship. Please see our return / warranty policy.
- Made in the USA.
The total weight displayed near the 'add to cart' button includes guy lines, sewn in linelocs, taped seams, and a stuff sack. A piece of repair tape is included with the tent. Your choice of canopy material will change the total weight.
*8x Stakes are required but are not included. We have a variety of Ultralight Stakes to choose from.
Peak height: 48" (122 cm)
Ridgeline width: 53" (135 cm)
Width including vestibules: 86.5" (220 cm)
Vestibule space: 20.75" (53 cm) depth on each side
Length: 100" (254 cm)
Peak height: 48" (122 cm)
Floor width: 44" (114 cm)
Floor length: 8 feet (2.44 meters)
Floor Area: 29.3 square feet (2.72 square meters)
Zipper entry height: 36" (91 cm)
Packed Size: 6" diameter by 12" tall (15 cm x 30 cm), 340 cubic inches (5.6L).
Stuff Sack Size: 7" diameter by 13" tall (18 cm x 33 cm) Medium-Plus. The intentionally loose stuff sack makes packing easy and it will squish down in your backpack.
- Our tents are made from Dyneema® Composite Fabric. Dyneema® Composite Fabric has several advantages over other materials:
High strength to weight ratio – the material can handle high wind force and does not tear easily.
Chemical free, PFC free
Waterproof – there is no DWR or coating to worry about wearing out. The material will not absorb significant water that will add water weight to your pack
Stretch-free – the tent will stay taut all night. Nylon material by comparison can stretch and sag, especially if it gets wet.
Taped seams – our seams are sewn for strength then taped water tight. The tie outs have bonded reinforcements for high strength. No seam sealing will be necessary!
Easily repairable – Any damage can easily be fixed in the field with our Dyneema® Composite Fabric Repair Tape.
- This tent is semi-transparent. In bright sunlight, a fuzzy silhouette of a person sitting inside the tent would be visible, but you cannot see any details. It has a suitable amount of privacy for changing clothes.
In lower light (such as in the evening or at night), you cannot see through at all. We also have thicker, darker material available as an upgrade that you can choose. Another nice thing about this material is that you can see the outlines of trees and your surroundings for a more immersed outdoor experience.
- This tent has fully enclosed .67 oz/sqyd (22.7 g/m²) insect screen. The holes in this screen are super tiny, so even the smallest insects cannot get through. Our tent screen is about 30% lighter than comparable Noseeum screen with no noticeable decrease in durability.
- The bathtub floor is made from 1.0 oz/sqyd Dyneema® Composite Fabric. This material weight is more than twice as thick as the canopy material and is more resistant to abrasion and punctures. It is also easy to patch with tape.
- Lineloc V adjusters are sewn to all tie outs. Bright yellow Dyneema® Z-Line cord is cut and attached for you. The yellow lines are very easy to see night or day, and Dyneema® has very low stretch.
- The expected life span of this shelter is at least one full 2500+ mile thru hike, or many years of casual use with some care.
Made with Bio-Based Dyneema® Fiber
Reduce your carbon footprint with DSM’s bio-based Dyneema® fiber technology. Sourced from renewable, bio-based feedstock, it is the first ever bio-based ultra-high molecular weight polyethylene (HMPE) fiber. Commit to sustainability and help reduce our reliance on fossil fuel resources and rely on the trusted performance of the world’s strongest fiber™. Click here to learn more about our sustainability initiatives.
Made in the USA.
Click here for a printable version.
Guylines are pre-cut and attached for you. Linelocs are sewn in place for adjusting the lines. If you choose to switch out your lines for a different cord these are the default lengths:
Peaks (2x) - Cut 102 inches (259 cm) and tie a stake loop at 40 inches (102 cm). The long end attaches to the tent and the short end attaches to the door hooks.
Corners (cut 4x) - 32 inches (81 cm).
Ends (cut 2x) - 54 inches (137 cm)
In windy conditions orient the end of your tent with the overlapping storm doors upwind. The Zpacks labels at the corners indicate the upwind end of the tent
Splash-up can occur when camped on hard packed surfaces during heavy rain. Our tall bathtub floor and overhanging canopy helps to keep mud and water from splashing up into your tent, but for best results please choose camp spots on leaves or pine needles when possible. Remove any pointy twigs and sharp objects to protect your tent floor but leave as much rain-dampening cushioning as possible to minimize the potential of splash-up.
- Adjust your two trekking poles to around 48 inches (122 cm). If you expect your pole tips to sink into the ground, add a couple inches to compensate.
- Give your corner guylines some slack. Stake out all four corner guylines at a 45 degree angle, roughly straight off the corner points.
- Insert the front trekking pole outside the screen with the handle at the peak and the tip in the ground. Stake the front line.
- If the peak is too high, tighten the front corner lines. If it is too low, loosen them.
- The corners of the tent should be about 6-8 inches (18cm) off the ground.
- Insert the back trekking pole the same way and stake it out.
- Stand the Riser Rods at the ends of the tent vertically and stake them out. For additional stability, use the loops at the bottom of the Riser Rods to attach additional stakes.
- If the walls of the tent aren't smooth, you may need to reposition the corner stakes or adjust the lines tighter.
- If the back corners are too low, loosen the back guylines, and tighten the main peak line to pull the front of the tent down and raise the back up. It should be about 6-8" (18 cm) off the ground all the way around.
Any of the four doors can be clipped down, or rolled up independently. The storm doors can be clipped down to the front center guylines, or rolled up depending on the weather. Leave at least one down-wind door open for air flow unless the weather is very bad.
All Zpacks shelters have taped seams and bonded tie outs! No seam sealing necessary.
Click here for full instructions on how to wash our Dyneema® Composite Fabric tents and tarps.
Tall Hiker, Love the DupleXL!!
Last year I did several long section hikes on the AT with a Duplex. Liked the tent but I’m 6’4” and my head and feet brushed the roof whenever I’d lay down. Just finished a 10 day section hike with my new DuplexXL and love it! I fit perfectly. Thanks ZPacks team for hooking me up with this new design; sincerely appreciate your thought and consideration for putting this together for the guys like me.
Best UL tent IMO
So nice !
Love this new tent!!
I totally love my Duplex tent… but this one is even better. I’m 6’4, so the extra length is great. Also love the extenders on each end that help keep the edges of the tent a little higher. It all adds very little weight, although it is a bit bigger in the stuff sack. Still my favorite tent!
Hello, Overall it is what i expected, I'm 6'3" and there is PLENTY of room. My only complaint albeit minor is the size of the bag it came with. I watched the video about how to pack it and tried it several times - it was hard but would be significantly harder on the trail. Did you have a bag that was 4-6" longer?? Thanks
Extra Long for Tall People, Excellent Tent
Another excellent tent from Zpacks. This is my second purchase; my other one is a Triplex. Although not as wide as the Triplex, this extra long DupleXL is great for tall people like my son. Since he is well over 6 feet, this tent allows enough space above his head to prevent excess condensation. Additionally, they added these odd, but effective, stays (stiffeners) on the sides; this ensures you get a good "eave" for interior condensation to run down the sides and through the side mesh (between the ceiling and the bathtub). I picked the Spruce Green for just that extra thickness/strength sacrificing a few ounces (hopefully it will last a long, long time). Even though we used it in very humid conditions and heavy rain, there was no leakage and no condensation. We used a tyvek ground sheet as we have used it on very sharp rocks.
